SUGGESTED OPERATING LIMITS
Temperature:-20℃~180℃
Speed:≤10 m/s
Pressure:≤1.0Mpa
COMBINED MATERIAL
Rotary face:Stainless steel/Carbon/Sic/Tc
Stat Ring:Carbon/Ceramic/Sic/Tc
Features：
For plain shafts
Single seal
Unbalanced
Rotating conical spring
Dependent on direction of rotation
Advantages：
Universal application opportunities
Insensitive to low solids content
No damage of the shaft by set screws
Large choice of materials
Short installation lengths possible (G16)
Variants with shrink-fitted seal face available
Recommended applications：
Chemical industry
Pulp and paper industry
Water and waste water technology
Building services industry
Food and beverage industry
Sugar industry
Low solids content media
Water and sewage water pumps
Submersible pumps
Chemical standard pumps
Eccentric screw pumps
Cooling water pumps
Basic sterile applications
