Suggested operating limits

Temperature: -20 ～ 180℃

Speed: ≤20m/s

Pressure≤1.5 Mpa

Combined material

Rotary face: Stainless steel/Carbon/Sic/TC

Stat Ring: Carbon/Sic/TC

Seat Type:Standard AS-S09,Alternative AS-S04/S06/S92/S13

Features

⑴For plain shafts

⑵Single seal

⑶Unbalanced

⑷Super-Sinus-spring or multiple spring rotating

⑸Independent of direction of rotation

⑹Variant with PTFE secondary seals for high chemical resistance(M78N)

Advantages

⑴Universal application opportunities

⑵Efficient stock keeping due to easily interchangeable faces

⑶Extended selection of materials

⑷Insensitive to low solid contents

⑸Flexibility in torque transmissions

⑹Self cleaning effect

⑺Short installation length possible(G16)

⑻Pumping screw for media with higher viscosity(M7..F)

Recommended applications

⑴Process industry

⑵Chemical industry

⑶Pulp and paper industry

⑷Water and waste water technology

⑸Shipbuilding

⑹Lube oils

⑺Low solids content media

⑻Water/sewage water pumps

⑼Chemical standard pumps

⑽Vertical screw pumps

⑾Gear wheel feed pumps

⑿Multistage pump(drive side)

⒀Circulation of printing colors with viscosity 500...15,000mm2/s
