Suggested operating limits
Temperature: -20 - 180℃
Speed: ≤15m/s
Pressure≤2.5 Mpa
Combined material
Rotary face: Carbon/Sic/TC
Stat Ring: Sic/TC
Seat Type:Standard AS-S16,Alternative AS-S06/S09
Features
For unstepped shafts
Single seal
Balanced
Independent of direction of rotation
Encapsulated rotating spring
Advantages
Especially designed for solids containing and highly viscous media
Springs are protected from the product
Rugged and reliable design
No damage of the shaft by dynamically loaded O-Ring
Universal application
Variant for operation under vacuum available
Variants for sterile operation available
Recommended applications
Pharmaceutical industry
Power plant technology
Pulp and paper industry
Water and waste water technology
Mining industry
Food and beverage industry
Sugar industry
Dirty, abrasive and solids containing media
Thick juice (70 ... 75 % sugar content)
Raw sludge, sewage slurries
Raw sludge pumps
Thick juice pumps
Conveying and bottling of dairy products
